Welcome to cellPack’s documentation!

cellPACK

Continuous Integration Documentation Code Coverage

An algorithm to pack molecular recipes

Installation

[!NOTE] These are the basic installation steps. However, our recommendation for developers is to install with pyenv and pdm. See advanced installation instructions here.

  1. Install Python 3.9 and git. Update pip at least to 24.0.0.

  2. Clone this git repository. .. code-block:: bash

    git clone git@github.com:mesoscope/cellpack.git cd cellpack

  3. Create a new virtual environment and activate it. .. code-block:: bash

    python -m venv .venv source .venv/bin/activate

  4. Install the required packages for your operating system. Replace linux with macos or windows as appropriate. .. code-block:: bash

    pip install –upgrade pip pip install -r requirements/linux/requirements.txt pip install -e .

Run pack code

  1. example pack v1 recipe : pack -r examples/recipes/v1/NM_Analysis_FigureB1.0.json -c examples/packing-configs/run.json

  2. example pack v2 recipe : pack -r examples/recipes/v2/one_sphere.json -c examples/packing-configs/run.json

  3. example pack from remote : pack -r  github:recipes/NM_Analysis_FigureB1.0.json  -c examples/packing-configs/run.json

Run conversion code

Stable Release: pip install cellpack
Development Head: pip install git+https://github.com/mesoscope/cellpack.git

Documentation

For full package documentation please visit mesoscope.github.io/cellpack.

Development

See CONTRIBUTING.md for information related to developing the code.

Contributing cheat sheet

  1. pip install -e .[dev]

    This will install your package in editable mode with all the required development dependencies (i.e. tox).

  2. make build

    This will run tox which will run all your tests and lint your code.

  3. make clean

    This will clean up various Python and build generated files so that you can ensure that you are working in a clean environment.

  4. make docs

    This will generate and launch a web browser to view the most up-to-date documentation for your Python package.

Suggested Git Branch Strategy

  1. main is for the most up-to-date development, very rarely should you directly commit to this branch. GitHub Actions will run on every push and on a CRON to this branch but still recommended to commit to your development branches and make pull requests to main. If you push a tagged commit with bumpversion, this will also release to PyPI.

  2. Your day-to-day work should exist on branches separate from main. Even if it is just yourself working on the repository, make a PR from your working branch to main so that you can ensure your commits don’t break the development head. GitHub Actions will run on every push to any branch or any pull request from any branch to any other branch.

  3. It is recommended to use “Squash and Merge” commits when committing PR’s. It makes each set of changes to main atomic and as a side effect naturally encourages small well defined PR’s.

Introduction to Remote Databases

AWS S3

  1. Pre-requisites

    • Obtain an AWS account for AICS. Please contact the IT team or the code owner.

    • Generate an aws_access_key_id and aws_secret_access_key in your AWS account.

  2. Step-by-step Guide

    • Download and install the AWS CLI

    • Configure AWS CLI by running aws configure, then enter your credentials as prompted.

    • Ensure that Boto3, the AWS SDK for Python is installed and included in the requirements section of setup.py.

Firebase Firestore

  1. Step-by-step Guide

    • For dev database:

      • Create a Firebase project in test mode with your google account, select firebase_admin as the SDK. Firebase Firestore tutorial

      • Generate a new private key by navigating to “Project settings”>”Service account” in the project’s dashboard.

    • For staging database:

      • Obtain credentials:

        • Reach out to the code owner for the necessary credentials.

      • Configure the environment variables:

        • Create a .env file in the root directory.

        • Populate the .env file with the following variables:

          FIREBASE_TOKEN=KEY_JSON_FILE["private_key"]
          FIREBASE_EMAIL=KEY_JSON_FILE["client_email"]


          note: KEY_JSON_FILE is the content of the private key JSON file generated in the staging Firebase.

Docker

  • Install docker

  • Clone the repository locally, if you haven’t already: git clone https://github.com/mesoscope/cellpack.git

  • Ensure that you have valid AWS access key and secret to access the cellpack-results S3 bucket, usually stored in a ~/.aws/credentials file. If you have multiple accounts in your credentials files, ensure that the desured account is the default option.

  • We have two Dockerfiles in /docker, one that builds the Docker image to be run in AWS ECS, and one to be run in AWS Batch. To build one of the images, run: docker build -f [DOCKERFILE-NAME] -t [CONTAINER-NAME] . Rebuild the container if new files are added or changes are made to the codebase.

Batch Docker Image

  1. Build image, running docker build -f docker/Dockerfile.batch -t [CONTAINER-NAME] .

  2. Run packings in the container, running: docker run -v ~/.aws:/root/.aws -e recipe=examples/recipes/v2/one_sphere.json -e config=examples/packing-configs/run.json [CONTAINER-NAME]

  3. Verify that the packing results are saved in the cellpack-results S3 bucket. You should see a botocore logging message indicating that the credentials were successfully loaded.

ECS Docker Image

  1. Build image, running docker build -f docker/Dockerfile.ecs -t [CONTAINER-NAME] .

  2. Run packings in the container, running: docker run -v ~/.aws:/root/.aws -p 80:80 [CONTAINER-NAME]

  3. Try hitting the test endpoint on the server, by navigating to http://0.0.0.0:8443/hello in your browser.

  4. Try running a packing on the server, by hitting the http://0.0.0.0:80/pack?recipe=firebase:recipes/one_sphere_v_1.0.0 in your browser.

  5. Verify that the packing result path was uploaded to the firebase results table, with the job id specified in the response from the request in step 4.The result simularium file can be found at the s3 path specified there.

MIT license
